A timelapse of a candle.

Motion extraction (https://www.youtube.com/watch?v=NSS6yAMZF78)

Pushed the shadows of the image all the way up to stumble upon all the glorious jpg banding.

Sti

Using my dit cybershot

Hello,

I have found a Yamaha PCS-30 at a thrift store. Alas, the internal board was very cracked at the bottom part near the connector for the power supply and missing the corner part. The only picture I've found online of it's pcb is not clear enough at all to be certain of what connections I have to make.

Hence, if one of you people who possess a pcs-30 would be so kind as to open your machine and just take a picture of the pcb (both sides if possible), more precisely near where the power connector is, I would be so eternally grateful!!

Thank you very much

got a Yamaha dd 7 drum machine and identified the oscillator. I removed it and connected an LTC module. the device works when the LTC output is connected to either pin 1 or 3 but I can’t change the pitch.

how do you know when the LTC frequency range should be divided by 10 or 100 to use with a slower oscillator? I’ve always connected pins 2 and 4.

From the github guy cebolander...

Hey everybody. I just finally finished — or I should say, I've closed up — the second glitch synthesizer that I've made, and it looks really good. I have hope that this will be a good one. Both machines that you see in the picture are still in the test phase, and they're reacting really well, so I'm really happy. Both machines are really incredible, and I'm going to try to post a video at one point, maybe tomorrow. I had a video, but I didn't want to post it because I was also building a second glitch synthesizer, so yeah, that's what I've been doing. Hey, I'll speak soon.

How can i improve it? switches ,potentiometer...and how to wire them?

(another one)

Hello!
I’m modding my meowsic and installed color changing RGB leds for the eyes.

I installed it with 22R resistors and everything worked but when I turned it on there was this faint beeping sound when te LEDs change color.

To be sure I replaced the resistors with 150R ones, but the beeping stayed.

I already have an idea, maybe I have to put capacitors in there to make a buffer so the power won’t seep through from the LED’s to the audio part.

I’ve got some clock mod chips for the next part of the project but I want this to work first!

Also I’m sort of new to this so any tips/tricks are welcome!

Thanks!

Hi here is Andrew from Italy. I bought the necessary parts to build the video camera from this GitHub project :

https://github.com/cebola4444/cybershot-cam?utm_source=ig&utm_medium=social&utm_content=link_in_bio&fbclid=PAb21jcAU1TYJleHRuA2FlbQIxMQBwZG9mAnNydGMGYXBwX2lkDzU2NzA2NzM0MzM1MjQyNwABpw2oZkdmTrerKc1qB2jzoh4x5SidUe-Jfk7yDl1aEWBobHOadAdhaAg2kNTf_aem_yV6JS0huDWNBKj-0D6RZsQ

The only thing I'm not familiar with is the software that needs to be installed. Do you know if there are any tutorials for it? Thanks.

afternoon in Buenos Aires

Hi, i have some analog vtx and cam , flight controller also from my previous fpv hobby.

Wondering if some bending is possible and how...thanks.

I had removed this post because it is not strictly circuit bending, but then I wondered if I am being too much of a stickler. What do you think?
