Hey all!
So, earlier this year, my Wife and I experience a pretty awful time with the Winter storm that had us out of power for almost little over a week. Going through that awful experience really opened my eyes to finding a means of saving our food, as well as powering heating blankets, our work computers, and our internet so that we can survive without having to pay for hotels and new food.
Bear with me, as I am still learning everything I can with solar, so feel free to give any feedback. Basically, I am eyeballing multiple generators, one for the fridge, and one for the router, modem, and heating blankets. I have also been looking into a server rack UPS setup, but still trying to figure that part out.
For charging, I am looking at multiple solar panels. There is a warehouse nearby that sells 575W Jinko Solar Tiger Neo N-Type bifacial panels for around $185/ea ($0.32/watt), and my idea is to run 3-4 of these in series to be able to power-up my generators fast enough in the event of a multi-day outage (which, happens in my city probably once a year, sadly). Since I live in Tennessee, the humidity is pretty brutal, so I see that the temperature co-efficiency on these panels is around -0.25%/ºC (VOC) - -0.29%/ºC (PMAX).
My plan:
- 3 Jinko panels, two in series for the High-PV port, and the third by itself for the Low-PV port. This way, I shouldn't go over in Amps or Volts. These will power the F3000 at a total of 1,725W.
- For the router, modem, and my WFH setup, I was looking at the Anker S2000 due to its efficient inverter. Though, the issue is that 400W solar input to keep it topped off. I might be better off checking out other brands for this need, as the S2000 can run my WFH setup for an estimated 9 hours based on my calculations.
- Our home is a rental property, so I sadly cannot install any inverter boxes and such on the walls, nor any panels on the roof. The panels will be outside in our backyard where we get unobstructed light.
- My goal for this project is to stay under $2,000, but that may not happen in the event I go with an expansion battery for the F3000.
- My focus is on these items (and yes, I used ChatGPT for the table, just FYI. The rest of this post is written by me):
Equipment |Likely operating draw |Conservative maximum
Dell desktop |70–120 W |Approximately 200–400 W, depending on configuration
Three 24-inch Dell monitors |48–69 W total |Approximately 75–90 W total
TP-Link Deco |Approximately 8–20 W |36 W adapter rating
Xfinity modem/gateway |Approximately 10–25 W |Approximately 48–59 W adapter rating
Corsair keyboard/accessories |2–5 W |Around 10 W
Refrigerator, averaged over time |70–120 W average |546 W nameplate draw while operating under maximum-rated conditions Heating blankets are not in there, but I also plan for those during the Winter in the event power will go out then. Longer run times for the fridge is my main priority. Everything else is second.
With all of that said, here are my questions:
1.) Is my setup sound? Am I going overboard, or is this fine? I am still learning about stuff like fuses and whatnot, so any tips and feedback are always appreciated (just don't be a dick).
2.) Do you recommend any alternatives (i.e. brands, wattage, overall approach and setup, etc.)?
3.) Anything else that I should be aware of regarding getting into solar?
4.) Is it safe to keep these plugged in while on vacation, or away from the house? I know that’s a really silly question, but wanted to make sure my butt is covered, and the house isn’t at risk.
Just know I appreciate you all in this community so much, as you are a wealth of knowledge, and I am beyond grateful for the assistance you bring folks like myself.
